Manual Control Car Spray Booth Automotive Paint Booth With Celling Filter
Contact Person : Victoria
Phone Number : +8615935349527
WhatsApp : +8615935349527
| Minimum Order Quantity : | 1 SET | Price : | $6000-$15000 |
|---|---|---|---|
| Packaging Details : | Standard Package | Delivery Time : | 5-8 weeks |
| Payment Terms : | T/T, Western Union | Supply Ability : | 100 PCS Per Month |
| Place of Origin: | Shanghai,China | Brand Name: | SINOCAR |
|---|---|---|---|
| Certification: | CE/CCC/ISO 9001 | Model Number: | SB-001 |
|
Detail Information |
|||
| Curing System: | Included | Safety Door: | Rock Wool Panel Fire Resistant Wall Without Glass |
|---|---|---|---|
| Lighting: | LED | Control: | Manual |
| Filter System: | Floor Filter & Celling Filter | Safety: | Explosion-proof |
| Front Door/Safety Door: | Three Offs Sheetmetal Front Door With Glass | Max.Working Temperature: | 80℃ |
| High Light: | Vehicle Spray Booth 7900mm,Vehicle Spray Booth 2700mm,Manual model car paint booths |
||
Product Description
| SINOCAR SB-005(LUXURY SPECS) | ||
| Basement Structure | Basement | Steel structure, 2 row of checked plates and 3 rows of vein boards,with the loading capacity of 7T |
| Basement Height | 300MM | |
| Ramp | Inner ramp/external ramp | |
| Booth Cabin | Panel | 1.Colorful steel skin panel. Rock wool panel fire resistant wall 5cm, two layers 0.35mm steel cover with fire resistant thermal insulation materials in. 2.Galvanized steel roof panel, anti-flame |
| Front Door/Safety Door | Four offs all glass front door | |
| Safety Door | sheetmetal door with glass | |
| Lighting System | Top Lighting | LED Ceiling lights:8 groups×3pieces =24pieces ×16W, with powder-coated light box |
| Wall LED boards | 8 sets of LED light 3*16W=48W | |
| Filter System | Ceiling Filter | Ceiling filter can capture granules bigger than 4μm, filtering rate> 98% |
| Intake&Exhaust System | Intake Fan | 2×5.5KW YDW double-intake centrifugal fans, total air capacity: 28000m³/h |
| Outlet fan | 2.2KW centrifugal fans | |
| Exhaust Duct | Straight tube and bend | |
| Heating System | Halogen Infrared Heating | Infrared heating lamps with explosion resistant ,220V/380V,24KW, 8 sets Halogen infrared barking lamps, every set with 3*1KW barking lamps |
| Max.Working Temperature | 80℃ | |
| Heating Up Time | 5-8min | |
| Control System | Control Panel | Intelligent controlling system, lighting switch, spraying, heat spraying, baking, temperature controller, time setting, emergency stop |
| Functions | Spray, Bake, Lighting and Emergency Stop | |
| Size | Inner Size | 7900*4100*2700mm (L*W*H) |
| Outer Size | 8000*5300*3300mm (L*W*H) | |
| Remarks: 1.Quantum Graphene Heating System are optional according to the requirement. 2.Electric and Diesel Heating System are optional according to the requirement. |
||
The Vehicle Spray Booth, also known as the Automotive Paint Booth, is an essential piece of equipment for vehicle painting. It is designed with a filter system that includes both floor filter and ceiling filter to ensure a clean painting environment. The front door is constructed with three offs sheetmetal with glass to provide safety and security. It is also equipped with LED lighting for optimal visibility, and an explosion-proof safety system to prevent potential accidents. This Vehicle Painting Booth is an ideal tool for any automotive painting project, providing a clean and safe environment for an efficient painting process.
The Car Spray Booth (Model: SB-001) by SINOCAR is designed for vehicle painting and automotive spray applications. It is crafted with CE/CCC/ISO 9001 certified components, ensuring safety and efficiency. The Curing System included in the booth ensures a perfect finish for any vehicle painting job. The Safety Door is designed with Rock Wool Panel Fire Resistant Wall Without Glass for maximum security, while the Filter System is composed of Floor Filter & Celling Filter. The Lighting of the booth is provided by LED lights for perfect vision. The minimum order quantity of the Car Spray Booth is 1 SET, and the Price is private chat to get. The Delivery Time is 5-8 weeks, and Payment Terms are T/T, Western Union. The Supply Ability is 100 PCS Per Month.
Brand Name: SINOCAR
Model Number: SB-001
Place of Origin: Shanghai,China
Certification: CE/CCC/ISO 9001
Minimum Order Quantity: 1 SET
Price: Price peivate chat to get
Packaging Details: Standard Package
Delivery Time: 5-8 weeks
Payment Terms: T/T, Western Union
Supply Ability: 100 PCS Per Month
Filter System: Floor Filter & Celling Filter
Front Door/Safety Door: Three Offs Sheetmetal Front Door With Glass
Safety: Explosion-proof
Curing System: Included
Max.Working Temperature: 80℃
SINOCAR SB-001 is a high-grade car spray booth, designed to offer best in class painting performance for your vehicle. It offers superior safety and air filtration systems, as well as a wide range of customizable features. The booth is equipped with an explosion-proof front door and ceiling filter, as well as a floor filter for added safety. The maximum working temperature of the booth is 80℃, ensuring your vehicle remains safe during the painting process. The curing system is also included for faster and more efficient painting.
Purchase a SINOCAR SB-001 car spray booth today and enjoy superior painting performance for your vehicle. We provide competitive prices, quick delivery times and secure payment methods, as well as a minimum order quantity of 1 set. Contact us today to learn more about our custom vehicle painting booth.
At Car Spray Booth, we provide a wide range of technical support and service to ensure that your car spray booth is working correctly and efficiently. Our technical support and service cover the following areas:
We also offer custom services for any specific needs that you have for your car spray booth. We have a team of experienced technicians who are available to help you with any of your technical support and service needs.
